Sonaca Aircraft performs static and fatigue analysis on the Sonaca 200 with the support of Sonaca’s “Numerical Methods” team



  •       Static and fatigue analysis on the Sonaca 200 has been performed under Sonaca’s SONIA virtual sizing environment
  •       Sonaca Aircraft is currently in the final phase of the Sonaca 200 flight test programme
  •       The delivery of the first Sonaca 200’s is scheduled for the beginning of 2018

The static and fatigue analysis for the Sonaca 200, a single-engined two-seater designed for training and leisure flights, were undertaken entirely within the SONIA environment[1]. SONIA is a structural computing environment that has been developed by the aerospace equipment manufacturer Sonaca, and embed:

  •  the best computation software using the finite element method (SAMCEF, ABAQUS or NASTRAN);
  • sizing methods developed over more than 40 years by Sonaca’s design office.

SONIA automates and standardises our sizing process. It covers structure idealisation, load application, launch of analyses as well as result post-processing according to design requirements“, explains Albert-Paul Gonze, Head of Sonaca’s “Numerical Methods” team.

SONIA: a proven environment

This approach has been developed over more than 15 years and has been validated by numerous tests. It is used for certifying Sonaca aircraft. It allows innovation in the design of aircraft and more efficiency in terms of weight reduction. “SONIA is able to solve very complex problems such as impact resistance, de-icing, non-linear behaviour, large deformation, fatigue analysis and damage tolerance, etc.“, Albert-Paul Gonze says.

The Sonaca 200’s 800 parts and 15,000 rivets

We naturally turned to Sonaca for the sizing of the Sonaca 200. The Sonaca Group has significant experience in the sizing and certification of aeronautical structures for CS-25 category aircraft[2] whose certification criteria are much more stringent than those for the Sonaca 200“, says Carl Dewandel, Head of Structure Compliance at Sonaca Aircraft. “In the specific case of the Sonaca 200, the digital model included the 800 parts and 15,000 rivets that make up the plane. SONIA has made it possible to precisely calculate the safety coefficients and to maximise the reliability of all the elements“.

Final stage of Sonaca 200 flight tests for EASA CS-VLA certification

After successfully passing the static test programme as well as all stability, noise, vibration, performance and stall tests, the Sonaca 200 begins the final flight-test phase (spin test). Sonaca Aircraft completes the steps to obtain DOA[3]. Delivery of the first aircrafts is still scheduled for the beginning of 2018.


[1] SONIA: Structure design Environment, Numerical Analyses & Virtual Testing, Sonaca.

[2] EASA Category CS-25: Large Aeroplanes.

[3] DOA: Design Organisations Approvals, EASA.

Pictures © Sonaca: Views of the different stages of sizing.
